LED Lighting 60 Watt Constant Voltage LED Driver IP67 24V DC , High Reliability

Product Details:

Place of Origin:	China
Brand Name:	DongDaHua
Certification:	CE,RoHS
Model Number:	PF-60-12

Payment & Shipping Terms:

Minimum Order Quantity:	10
Price:	/
Packaging Details:	as for your requirement
Delivery Time:	as per your order quantity
Payment Terms:	TT,paypal
Supply Ability:	4000pcs/Day

Contact Now

Detailed Product Description

Product Name:	Constant Voltage LED Driver	DC Output Power:	60W
DC Output Voltage:	12V 24V	Input Voltage Range:	110-240V AC
Waterproof Grade:	IP67	Input Frequency Range:	47Hz~63Hz
Highlight:	waterproof led driver

Overload Protection 60W Constant Voltage LED Driver IP67 High Reliability

Quick detail:

Power: 60W

Input: AC110-264V

Output: DC 12V 24V

Size: 160*41*32

Certificate: CE&ROHS

Warranty: 2 years

Description:

1. Protections :Short circuit/Overload/Over temperature

2. Cooling by free air convection

3. IP67 design for indoor or outdoor installations

4. 100% full load burn-in test

5. Suitable for LED lighting

6. Products through CE& ROHS certification

Descriptions:

Parameter	Model: PF-60
DC output voltage	12V±5%	24V±5%
Rated output current	5A	2.5A
Output current range	0-5A	0-2.5A
Ripple and Noise	120mVp-p
DC output power	60W	60W
Efficiency	85%	85%
Input voltage range	110-240V AC
Short-circuit protection	Damage free short-circuit protection 3 times or more with automatic restoration
Overload protection	105-150% hiccup with automatic restoration
Temp.coefficient	±0.03%℃ ( 0-40℃ )
Voltage tolerance	Input-output range: 1.5KvAC
Working environmental temp.	-10℃~+40℃
Waterproof grade	IP67
Input frequency range	47Hz~63Hz
Storage temperature	-20℃~+85℃
Dimension	1604132 mm
weight	0.38 kg

Features:

* constant voltage design
* Universal AC input/Full range
* Withstand 300VAC surge input for 5 seconds
* Epoxy encapsulated with IP67 level
* Protections:Short circuit/Overload/Over voltage
* Cooling by free air convection
* Small and compact size
* Fully isolated plastic case
* Suitable for LED lighting and moving sign applications
* 100% full load burn-in test
* Low cost,high reliability
* 2 years warranty

LED lighting 60 Watt Constant Voltage LED Driver IP67 24V DC , High Reliability

Application:

It’s suitable for an extremely wide range of applications, including:
LED, CCTV camera;
Communications and security products;
LED Strip Lighting/ LED lamp / LED Light, LED / LCD display.
