Computer Switching Power Supply

SWITCH POWER SUPPLY SINGLE TYPE NES SERIES NES-75W

1. Features

1. All using 105°C ling life electrolytic capacitors.

2. Protections: short circuit/ OLP/ OVP

3. Withstand 300VAC surge input for 5 seconds.

4. High operating temperature up to 70°C withstand 5G vibration test.

5. Miniature size, high power density.

6. High efficiency, ling life and high reliability.

7. 100% full load burn-in test.

8. Suitable for critical appllications.

9. 2 years warranty

10. NES-75-24 Single Voltage SMPS Switching DC Regulated Power Supplies 36V PSU

2.Specification

1. AC Input voltage range: 88-264VAC universal input

2. AC inrush current (max): cold start, 40A at 230VAC

3. DC adjustment range: ±10% by potential meter for single output: CH1-5%~10% by potential meter for multiple output.

4. Overload protection: 110%~150%

5. Over voltage protection: 115%~135% rated output voltage, hiccup mode, auto-recovery

6. Withstand voltage: I/P-O/P: 3KVAC, I/P-FG:1.5KVAC, O/P-FG:0.5KVAC, 1 minute.

7. Working temperature: -20-+60°C ( refer to the derating curve for diferent models)

8. Vibration: 10-500Hz, 2G 10 min/ 1 cycle, period for 60 min each along X, Y, Z axes.

9. EMC standards: EN55022 class B,EN61000-3-2,3,EN61000-4,2,3,4,5,6,8,11,ENV20504,EN61000-6-2(EN500282-2)

10. Connection: Terminal block for input and output

11. Dimension (L*W*H): 159*98*38 mm

3. Mechanical Dimension:

4. Certificates:

5. Please Note:

1. The testing condition for the parameter above is: 230VAC input, rated load, 25°C 70%Rh, Humidity.

2. Error, include the setting error, line stability and load stability.

3. Wave test: adopting "A12" double wire for 20MHZ, and 0.1uF&uF capacitor short-circuit for interrupting.

4. Inlet Voltage Stability test: when is over load, the lowest voltage of inler is representative to the highest voltage.

5. Load stability test: the load is from 0% to 100%, others 60%.

6. Total stability test: the load is from 0% to 100%, others 60%.
