Computer Switching Power Supply

Characferisifcs:

Input voltage range: AC 90V ~ 264V 47-63Hz

Rated output rating: Load regulation: ±5% 36W Max.

Output no-load voltage: 105% output voltage Max(Nom.)

Inrush current (Cold): 80A Max.

Protection: OCP/ OVP/ SCP

Dielectric strength: Input – Output 3.0 KV for 1 minute

Insulation resistance: 500VDC 50MΩ Minimum

Efficiency: 70% Normally @ rated load

Ripple & Noise: 1% output voltage Max.

Line regulation: ±1%

Hold up time: 3ms

Temperature rise: 95 °C Max. @ rated load / Class B

Applicable standard: UL60950, IEC-60950/ EN60950

Safety Agency approved: UL/CUL/CE/GS/C-tick/FCC/CCC

Normal operating environment: 0°C ~ 40°C 20% ~ 80% R.H

Storage environment: -20°C ~ 70°C 20% ~ 90% R.H

Dimension: L120*W53*H32mm

1.5m output cord, 1m input cord

2.1*5.5mm & 2.5*5.5mm DC plug

led light power supply regulated dc power supply

• Customized designs are welcome
• OEM orders are also accepted
